How to configure Internet and MMS on the CECT P168


*** UPDATED *** (New link at the end)

Many people are trying to connect to internet and send or receive multimedia messages with the CECT P168 without luck.

I've got mine working after searching a lot for the correct settings so i decided to build a page with a database with this info. It depends on the country you live and the company that gives you the phone service.

It has almost every country and carriers in the world.

When you get to the data for the specified carrier you should write it down and change those values in the following instructions at the words in italic and bold . These words are the sames as the fields in the results page.

The lines starting with a * are options on the phone (menus, buttons, icons, etc)

Internet Settings

* Main Menu
* Entertainment
* Services
* Data Account
* GPRS
- Find one free account (like Account 8, etc)
* Edit
- Change 'Account Name' and put the value COMPANY (remember, you have to change this for the one on the table)
- In 'apn' field put the value APN (again, remember)
- Fill the fields username and password with the ones on the table USER and PASSWORD
-Click 'Done' and say Yes to Save.

* Main Menu
* Entertainment
* Services
* WAP
* Settings
* Edit Profile
- Find one free account (like Profile 8, etc)
* Edit Profile
- Rename Profile and put the value COMPANY
- In Homepage field put the value HOMEPAGE
- In 'Data Account' select GPRS and then the account created before.
- Select 'Connection Type', choose HTTP and click OK
- Fill in the fields Proxy Address with PROXY and Proxy Port with PORT. Then click OK
- Fill the fields username and password with the ones on the table USER and PASSWORD
* Go back and Activate Profile

We are ready to navigate. Try it on


and then choose homepage or Enter Address.




MMS Settings

* Main Menu
* Entertainment
* Services
* Data Account
* GPRS
- Find one free account (like Account 8, etc)
* Edit
- Change 'Account Name' and put the value 'COMPANY MMS' (like 'MOVISTAR MMS')
- In 'apn' field put the value APN
- Fill the fields username and password with the ones on the table USER and PASSWORD
-Click 'Done' and say Yes to Save.

* Main Menu
* PIM
* Messages
* MMS
* Message Settings
* Server Profile
- Find one free account (like Profile 8, etc)
* Edit Profile
- Rename Profile and put the value 'COMPANY MMS'
- In Homepage field put the value HOMEPAGE
- In 'Data Account' select GPRS and then the account created before (the MMS one).
- Select 'Connection Type', choose HTTP and click OK
- Fill in the fields Proxy Address with PROXY and Proxy Port with PORT. Then click OK
- Fill the fields username and password with the ones on the table USER and PASSWORD
* Go back and Activate Profile


If you need another country and company please let me know writing a comment. I will post it as soon as possible.


------>>> New page with list of settings by country and carrier <<<------


96 comments:

Susan said...

Does any one have the settings for Ireland-e-mail & mms
Sue Barron

Anonymous said...

Settings for AT&T or Cell One please?

Anonymous said...

I keep getting 'Connection Failed' trying to use internet, in UK on Orange.

Any idea?

sue said...

Please can i get config settings for (contract) o2 ireland.
Please.......
Cannot get it working at all
thanks

Steve said...

Hi, I stumbled accross this site, it has a huge list of internet settings for a whole lot of countries.

http://www.taniwha.org.uk/gprs.html

Minna said...

do you have the settings for Cellular One in US?
I can't seem to find them anywhere!

El Navegante said...

Added Ireland to the countries and also added AT&T, Orange and Cellular One for USA.

Anonymous said...

I found if you go on the nokia website and send your self the settings for the nokia 2610 mms & internet works fine

Anonymous said...

Thank you for all the great informtion....I noticed that you have provided set up details for MMS for several countries. Have you any information for Vodafone in Australia. Keep up the Great work....Cheers Brad.

Anonymous said...

does any body know how to configure internet and mms on the cect168 via USA T-MOBILE

blkbutterfly83 said...

I would like to know how to configure my cect P168 to be able to download MMS and use the internet and whatever I'm doing isn't working. Please help!

Wam said...

HELLO! I really need the configuration for the Dominican Republic, with Orange. please help! any help send it to wamx@hotmail.com

Anonymous said...

i can``t conect to the internet for t- mobile in usa how can i do it ?????

Anonymous said...

Tmobile for united states does not work...I cannot open my picture messages, only regular text messages.

Anonymous said...

HELLO.. I CURRENTLY HAVE SUNCOM AND I NOTICED THAT IT DOES NOT APPEAR ON THE CHART, CAN ANYBODY TELL ME HOW TO SET UP THE INTERNET ON MY COMPANY??? ID REALLY APPRECIATE IT, MY E-MAIL IS MIKE20PR@HOTMAIL.COM PLEASE HELP!!!!!!!!!

Anonymous said...

The mms & internet settings for the p168 are the same as the nokia 2610 so if you send the settings from your service provider to your self it will work

Anonymous said...

For all of those who have been having problems with the above mentioned topic, I have good news. I have all the settings you need, and you don't need to buy online manuals or search day and night through all the forums. This phone (P168) shadows the WAP/GPRS and MMS of the Nokia 2610. What this means is all you have to do is go to the Nokia web site and input that you have this phone. The site will then ask for your mobile number and what not. Once that is done, you will receive the configurations via SMS (you will have to do this for each setting you need to configure). On your mobile, go to your new message. You should be able to install directly from this point. And that's that! Now, for the SMS settings. If you've had problems with other Suncom phones and their SMS settings, you would usually call them and they will give you a number to input into the phone. This is the Service number, and it is universal for all Suncom phone (SMS wise). On your mobile, go to main menu (house icon)>PIM(person icon)>messages(envelope icon)>SMS. Once in option, select Message Settings. Select Profile Setting. Edit the first profile. You will see two lines (one is your profile name; the other is the SC Address). In the first line, label it whatever you'd like (I labeled it SunComWeb). Go to option and press Done. Now, on the second line, edit it with the following number +17043453115. Once you've done this, you should have all your desired functions in working order.

Anonymous said...

Do you have the settings to use Internet and MMS for Telstra In Australia

Anonymous said...

How do I find my user and password for my internet and mms settings?

Anonymous said...

I forgot my security code!!! how do i change it? help plz!!!!

Anonymous said...

hey do anyone out there know how to do a hard reset or a reset option from factory mode or engineer mode. if anyone know this would really help me out thank you.

Anonymous said...

is it possible to have settings for french operators please

Navegante said...

We are trying to get as much settings of carriers as possible.
The ones asking settings for their country, please tell us the carrier name to cectp168re@gmail.com
In that way if we found them we can send you an email previously to the chart update.

Anonymous said...

I just bought a CECTp168 phone worked great, until TODAY

phone shuts off, i power it one, it asks if i want to upgrade to new daylight time zone or something.

I want to click NO , but my touch screen doesnt respond! the only key that works is the END key, and it immediately pops up the keypad to make a phone call, i cannot escape anything and the touch scrreeen doesnt work, only way i can power down the phone is by yanking out the battery

what do i do? is there a way i can reset it?

Dave T said...

These are the settings for ROGERS in Canada
account name Rogers GPRS
APN goam.com or internet.com
User wapuser1 Pass wap
Homepage http://mymobilehomepage.rogers.com
IP 172.025.000.107
Service HTTP
Port 80

MMS Settings
Account Rogers MMS
Homepage http://mms.gprs.rogers.com
APN media.com
User media Pass mda01
IP 172.025.000.107
Service WAP
Port 9203

Anonymous said...

I found the Optus (Australia) setting requirements!

Optus Zoo
Homepage: http://networker.optus.net.au/wap/index.wml
APN: Postpaid - wap.optus.net.au
Prepaid – prepaidyesoptus
Gateway/Proxy IP Address: 202.139.83.152
Port for WAP 1 handsets: 9201 – non secure
9203 – secure
Port for WAP 2 handsets: 8070

Optus MMS
Home page: http://mmsc.optus.com.au:8002/
Primary Proxy: 61.88.190.10
Port for WAP 1 handsets: 9201
Port for WAP 2 (newer) handsets: 8070
APN: mms

Optus Internet
Dial up number: *99#
Access Point: internet
Preferred/Alt DNS: 202.139.124.225
Optus Mobile Technical Support Centre
Phone: 1300 307 937 Mon-Sun 24Hrs
Standard Optus GPRS Settings

E-Mail Options
There are 2 common ways to view email with a GPRS device:
Email Client or Wap Email
Both require an email account with an email provider be established. The settings for
this account will be required to continue here.
Required info from Email Service Provider:
email address
email account password
incoming mail server type – (normally POP3)
incoming email server name (for Optus customers enter mail.optusnet.com.au)
outgoing email server name (for Optus customers enter mail.optusnet.com.au)
Email Client Requires Internet Profile Settings:
proxy enabled
primary proxy: 202.139.124.225
outgoing (SMTP) port: 25
incoming (POP3) port: 110
bearer: GPRS
APN: internet
authentication: normal
If the you have registered for Optus Zoo, Email setup can also be completed at the web
site:- http://www.optuszoo.com.au

Live TV
Check http://www.optuszoo.com.au for compatible handsets
Proxy: yes
Host Address: 172.22.1.2
Port: 554
Default Access Point: wap.optus.net.au
Lowest UDP Port: 6970
Highest Port: 32000
Navigate: Zoo, Entertain Me, TV, Live TV

I hope this helps as I spent 2 months google-ing trying to find this info!

lover said...

I jus got my p168. But I was unable to turn it on. I craged my batteries and tried every way possible. Unfortunately, nothing helped. it's been 2 weeks. There is no help form the seller in china.

can anybody help me?
Thanks

Navegante said...

To Lover:

Do you know anybody who has a CECT P168 Phone? That way you can try the batteries from that phone in yours and see if it starts.
Otherwise looks like a device problem and you should return it to the seller to receive another one.
Even if they are in China, i read that most vendors have a good return policy.
Could you contact them?
Have they an answer for you?

Good luck

Anonymous said...

URGENT: Please some help b/c i got my cectp168 hooked up to at&t and my geting a connection failed error. i called up the tech supprt line he gave the info i need to set in the phone. if anyone has other suggestions please help me out most appreciated.

Vancouverrite said...

2 questions please:
The phone sometimes turns off when receiving a call & also, what are the MMS & internet settings for Rogers Canada?
Thank you

D Fonk said...

Can I use the blackberry client with the 168+?

Anonymous said...

Got phone, worked cool until I started taking pics and messing with the video recorder then BAM!! memory card required came up..going thru phone..then BAM!! insert sim card pops up, wtf? I turn phone off and on again, works fine other than a screen freeze here and there.

sibylle said...

i set up mms and now, if i try to send one, i always get error "failed to resize file". what am i doing wron?

Anonymous said...

For all who wnat the SunCom Setting for WAP go to this site
http://europe.nokia.com/A4144889 and click on download standard settings, follow the instructions use the nokia 2610 for the settings. I live in Puerto Rico so i tried the one that says Sun Com Web Spanish link and it worked. For the MMS i have yet to figure that one but i will post results.

Anonymous said...

Other networks for configuratiojn are also on that site.......

Vancouverrite said...

This phone is such a piece of crap!! The phone microphone stopped working, it resets with most incoming calls & there is no one to stand up & take the warranty! I have nowhere to send this piece of crap to because the buyer has disappeared! STAY AWAY!!!!

Anonymous said...

I am trying to program my setting via your spread sheet for ATT in the US. There is no user name and password. I first used the setting for Cingular and they didn't work. Can you please help me out. THANK YOU.....

Anonymous said...

Does this phone have vibrate or silent mode? If so can someone tell me how to quiet this loud thing down while I'm at work?

Anonymous said...

Hi, I have suncom...could you please post the settings for internet for them....also I can receive and send text messages...but not picture messages(MMS)..could you possibly help with that too!

Thanks, Beth

Anonymous said...

I got this phone a month ago, I have been unsuccessful on configuring the MMS. I tried the above setup but nothing, it says "GPRS not configured". I have T-mobile service in USA, at this point...I REGRET buying this phone.

Daniel said...

I have the Cect A88, is there a way to make the "temporary internet files" or whatever a phone uses, download to the 1gb chip instead of the phone? Reason why I ask is because you cant go to alot of websites that are too large because the phone cant hold it i suppose?
Thanks!

Anonymous said...

I'm still trying to get the MMS picture messaging to work but have failed thus far. I've tried the US Rogers settings as well as the Canadian setting but nothing works. When I try to send an MMS, a little envalope with a red circle and a line through it flashes on the top left of the screen. Then an "error in communication" message appears. What am I doing wrong. I am from Canada. are there anyother setting i need to be aware of?

Anonymous said...

Here are the Rogers MMS settings in Canada that work for me. follow all the steps in this order and it should work.

1) First select services
2) then go to data account
3) select GPRS
4) then choose account 8 (or whatever one is unused) and rename the account name to "ROGERS MMS"
5) fill in the following
APN: media.com
User: media
Password: mda01
Auth. type : secure

6) hit the back button untill you reach the main screen.

7) Now, go to messages
8) then to MMS
9) then Message Settings
10) Server Profile
11) select a new profile and go to edit profile

12) rename profile to "ROGERS MMS"

13) enter the following

Homepage http://mms.gprs.rogers.com
Data Account: ROGERS MMS
Connection Type :HTTP
-Proxy Address: 172.025.000.107
-Proxy Port 8080
Username: media
Password: mda01

14) once entered, click back untill you have the option to "ACTIVATE PROFILE"

once activated you should be able to send MMS messages.

Thanks for listening

Klint K

Anonymous said...

who ever started this page,thanks a million,at first all i could do was get text messages,now i can send them also,i still cant figure out how to send pics,it just keeps saying sending for like 5 min.oh well thanks again.

The Useful Helper said...

This is the best resource on the net yet.
I am sorry I did not know about it before trying to figure out all by myself with my p168 and paid allot of money surfing with the wrong settings etc.

But still very good job you did here people thanks!

Anonymous said...

I must be doing something wrong. The instructions work until I get to Proxy and Port. My phone will only allow me to put numbers in there. I can't put the words Proxy or Port as instructed

blajabi said...

i have a setup instructions for t-mobile. internet, sms, mms, voicemail etc. if anybody need them. leave your email.

blajabi said...

ohh and its for cect a88. (for the top comment)

Neumann said...

Can Someone help me with setting the cect p168+ for cellular one network. i know nothing of sim cards...

Neumann said...

Oh, its Cellular One (Dobson Cellular) i think.

Neumanndk@yahoo.com

Anonymous said...

I need this MMS info for Centennial in the USA PLZ!!!!!

Navegante said...

Don't write the word PROXY or PORT. You need to exchange that for the value in numbers. That value is available at the link posted at the end of the article.

Please read the post. It says all that

Navegante said...

T-Mobile settings are already on the settings page.
If those don't work please let me know

Cellular One settings are also there

Navegante said...

Try this for Centennial MMS

APN: mmspublicwap.centennialwireless.com

PROXY: 063.009.231.135
PORT: 8080

Anonymous said...

anyone has info on the i9 version?

Anonymous said...

Pretty for sure the setting for the Tmobile usa did not work anyone have any suggestions?
Thanks,

Jdavis_0203@yahoo.com

Anonymous said...

Hi, in my cect p168 there is not any option that i can put down wap proxy, wap port, its service.
Only it has HTTP proxy , port and its service. How can i do for that.
Thanks in advanced.

Anonymous said...

mine keeps sayin invalide proxy scheme? why i have tmobile and im trying to get MMS.?
Please HELP
or send email to
bookingedwen@gmail.com

Noel said...

Hey mate, would you be able to get one for Virgin mobile Australia? I tried using Optus (they merged with them and are under their network) but it didn't work, thanks

Maurice said...

Does anyone know the settings for Bmoble MMS in Trinidad and Tobago? I need all the info such as IP address, Proxy and http. Please help a desperate soul!! Many Thanks!!!

Anonymous said...

Hi, I have tried everything to connect to the iternet on Virgin Mobile in the UK, just keep getting connection failed..if anyone can help, it would be appreciated..thanks

Anonymous said...

Im getting the same, "connection failed". what a pain in the ass. hate the phone already!!!! i can't download music either. it wouldn't turn on for an hour today and it had a full battery. can't get the internet. think i should have just forked out and got the real deal!!!

Anonymous said...

I have tried everything to get this phone to work. I did the nokia settings and the internet comes up but then says connection failed. I tried the mms settings and it says GPRS not subscribed. I am on T-Mobile. Please help!!!

My email address is t.dior05@gmail.com.

GIGI said...

hi there. i need settings for cect a88 on AT&T (USA). i would really appreciate it. thanks

Anonymous said...

have the p168c....trying to setup MMS, i am in the USA and have ATT....i have already tried everything here, maybe i'm entering it wrong or something....pls help

jason_coon@hotmail.com

thanks

Anonymous said...

finalmente sono riuscito....
thankssssssssssssssssssssssssssssss

Mario said...

Help! Help! I need to set the phone so I can receive and send MMS messages I got the new iFONE P168S I’m with Sun Com in Puerto Rico that change recently to T-Mobile. The instructions I see in the forum are not quite clear as far as steps. Can anyone help me set the MMS options? Please, Please…… send help to yito74@gmail.com

Anonymous said...

Unless I am Italian and I wanted to configure my cect p168 for MMS ... I have a card vodafone ... Please just know how to configure my cect p168 send me any instructions via e-mail ... thanks in advance. ...
this is my e-mail address: antonio92play@yahoo.it
excuse for the errors but I do not know speak English ....

Anonymous said...

kate

Whats the username and password supposed to be? internet still doesnt work!

cheryl ann said...

Hi, I'm from Trinidad. I need to know how the setting for BMobile to receive my mail,browse etc. Can anyone help please.

trivelle said...

I hv tried every step to get my mms and internet to work. Can someone pls help me. I have tmobile and I am in the USA. p168+ GSM phone. pls email me at trivelle1@yahoo.com. ASAP

GRIPPER said...

hi i have cectp168 and cant get my mms to work im on uk o2 sim contract my os provider cnt sort it as they dont reconise the phone can you help

thx

GRIPPER said...

pls help

Luis said...

my cect p168 simply doesn't recognise the signal of the operator. i'm from portugal and i use optimus and the phone should work here but for some reason it doesn't. can someone please help me?

Anonymous said...

Can you please post "internet configuration" for a Cect P169 plus the SMS & MMS using "Cable & Wireless" from Panama, Republic of Panama as provider????
Desperate here!!!

Anonymous said...

i tried using the nokia page, but i didn't receive any message? i entered *1 then my cell number number...can anyone tell me if i did something wrong?
mmelvi928@yahoo.com

Anonymous said...

I have a cect I9 phone and i couldn't figure out how to get the internet and mms.So i called T-Mobile(My cell phone provider)and they tranferred me to some one that helped me configure everything.So now i have t-zone's and the internet on my phone and i'm glad i called cause i didn't think they would help.

Anonymous said...

Just got a P169 and really need internet configurations for the Bahamas. please help. much obliged!

Anonymous said...

hello I have a cect i9 phone and can't get the Internet on it, I set it up but now it says request timeout can anyone helpme?, email me at elmejordelgenero@yahoo.com

Anonymous said...

Hi i have the i9 8 gb phone and i cant get my internet to work on it it keeps sayen gprs not subscribed and the company that i have is tmobile...so can u plz tell me how to change my settings

Anonymous said...

For T-Mobile:

go to services icon and select:
Data account > GPRS >
Select an empty slot. If no empty slot, just overwrite an existing one.
Account name: t-mobile
APN: wap.voicestream.com
the rest leave alone

Now go back to services icon and select:
WAP > Settings > Edit Profile >
Select an empty slot. If no empty slot, overwrite an existing one.
Edit Profile >
Profile Name: T-Zones
Homepage: wap.t-zones.com
Data Account: t-mobile
Connection Type: WAP, IP address: 216.155.165.050
the rest leave alone


For MMS settings try this:

Go to messages icon and select:
MMS > Message Settings > Server Profile >
Select an empty slot or overwrite an existing one.
Edit Profile >
Profile Name: t-mobile mms
Homepage: http://tmobile.com
Data Account: t-mobile
Connection Type: WAP, IP address: 216.155.165.050
the rest leave alone

I hope this helps. Best of luck

Sridhar said...

In India i have BSNL as the service provider.
I have made the internet & MMS settings in my p168+ as per your instructions.
To activate the GPRS account, the service provider wants me to get the settings from "www.gsmworld.com", as they do not activate china made mobile phones.
Please help.
Sridhar

TiffanyCrim said...

Okay so i did all ur steps and on mms it says! error connection what is wrond with it? and Then in the internet i go to homepage and it takes forever toload and when it does it says connection failed?? i am confused what do i do to get it to work it would help alot by the way my phone is CECT P168 I LIVE IN THE UNITED SATES thanks Tiffany..

Anonymous said...

I have tried every setting out there but nothing seems to work. I can get on the internet but when I try and download a picture message it sits at 0% until it says message download failed.

Abdulmateen said...

Hello,
I have the CECT i68+ model. I used the configs for AT&T in the US but I get a connection failure.
Can you please help me out.
Thanks

Anonymous said...

Stupid question...does this set up free internet access, or would I have to purchase the server through my provider?

Anonymous said...

Does anyone have MMS settings for Telstra? I contacted them and they said they had no listing for the P168C and suggested I buy another phone. The manufacturer said I should use the settings for the Sony Ericcson C510, but they don't work. ALL I get when I try to download a MMS is a blank screen with 'downloading' that sits at 0% for over half an hour.

Anonymous said...

I came across your v helpful web site by chance as I am having the same problems with a JC777s. I have made progress by following your instuctions but something is still not quite right. Thanks you for your assistance and the time you have taken in putting up this web help. JC777s is a Nokia 2610 clone as well. As I am unable to open messages, I cannot configure from Nokia web site so will keep using yours until I get it right. Thanks v much

Anonymous said...

I like others have connection failed having followed your good instructions. Does anyone know what to do to get connected please?
Cannot get MMS connection so will not be able to get details from Nokia. please help

thanks

jenna said...

I recently came across your blog and have been reading along. I thought I would leave my first comment. I don't know what to say except that I have enjoyed reading. Nice blog. I will keep visiting this blog very often.

Lucy

http://cellularaccessoriess.com

Anonymous said...

Interesting blog as for me. I'd like to read something more about this topic. The only thing it would also be great to see on this blog is a few pictures of some gadgets.
John Flouee
Phone jammer

Anonymous said...

Wanted to say, "Thanks, Tons!" This worked for my i9 as well. Glad I found your forum!

USA:T-Mobile User

Anonymous said...

hi i followed all your instructions but it just says conection failed i am on 02 uk.

Anonymous said...

Easy Earning money in online never been this easy and transparent. You would find great

tips on how to make that dream amount every Day.Sitting in the home earn around $100

perday. So go ahead and click here for more

details and open floodgates to your online income. All the best.

Thanks.

Anonymous said...

Hallo

I am from South Africa and I use vodacom. Can you please send me the settings to activate my internet please.

Thank you

magi said...

Thank you for posting such a useful, impressive and a wicked article./Wow.. looking good! Configure Internet Connection
